Automatic self-locking nuts torsion testing machine is widely applied in product self-
locking nuts, loosen nut, lock nut, four claw nut, screwing in nuts, insurance nut, thin rod nut screw link each nut torsion tests, such as can achieve maximum torque and torsional strength, yield strength and yield strength and other performance parameters.
Automatic selflocking nuts torsion testing machine adopts horizontal structure. Right side as the loading end, through the servo motor and deceleration system output torque, left for the mobile terminal; Can adjust the space according to the requirement of the sample. Torque sensor installed in the space above the bearing adjustment. Mobile terminal is by the linear guide, ensure that applying the torque due to clearance Angle is not accurate.
Since the lock nut torsion testing machine parameters:
The biggest test of torque：2000Nm
Minimum torque reading values：0.1Nm
Torque relative error value：±1%
Minimum torsion Angle reading values：0.1°
The biggest torsion Angle：99999°
Reverse speed：1-720°/min
The sample size：0.1-500mm
Size of the host：about 1260*500*1000mm
